Self-host tesserae

tesserae README

How to install tesserae

TESSERAE_SECRET_KEY, TESSERAE_IN_DOCKER, TESSERAE_BIND_PORT, TESSERAE_HOST_IP

mkdir ~/tesserae && cd ~/tesserae
curl -fsSLO https://raw.githubusercontent.com/dmellok/tesserae/main/docker-compose.yml
docker compose up -d

iwr https://raw.githubusercontent.com/dmellok/tesserae/main/install.ps1 -UseBasicParsing | iex

TESSERAE_DIR

curl -fsSL https://raw.githubusercontent.com/dmellok/tesserae/main/install.sh | bash

lxc launch images:debian/trixie tesserae
lxc shell tesserae
apt update && apt install -y git python3 python3.13-venv
# then the manual venv install:
git clone https://github.com/dmellok/tesserae.git && cd tesserae
python3 -m venv .venv
.venv/bin/pip install -e ".[dev]"
.venv/bin/python -m app.main

# Settings → Apps → App store → ⋮ → Repositories
# Add this URL, then install "Tesserae" and click Start:
https://github.com/dmellok/homeassistant-tesserae-addon

git clone https://github.com/dmellok/tesserae.git
cd tesserae
python3 -m venv .venv
.venv/bin/pip install -e ".[dev]"
.venv/bin/python -m app.main         # production: waitress, port 8765

How to configure tesserae

• --dev=offFlask dev server with auto-reload + debugger instead of waitress.

  Flask dev server with auto-reload + debugger instead of waitress.

• --host=0.0.0.0Bind address; set :: for IPv6 dual-stack where the OS supports it.

  Bind address; set :: for IPv6 dual-stack where the OS supports it.

• --log-level=infoRoot log level; wins over TESSERAE_LOG_LEVEL.

  Root log level; wins over TESSERAE_LOG_LEVEL.

  values: trace/debug/info/warning/error

• --port=8765Bind port for the web UI + API; an explicit flag beats TESSERAE_BIND_PORT.

  Bind port for the web UI + API; an explicit flag beats TESSERAE_BIND_PORT.

• --reset-passwordClears the stored admin password and exits; next request goes to /setup.

  Clears the stored admin password and exits; next request goes to /setup.

• TESSERAE_API_BASE=https://api.tesserae.inkBase URL for online features (template marketplace, community catalog). Only useful for development or a self-hosted API.

  Base URL for online features (template marketplace, community catalog). Only useful for development or a self-hosted API.

• TESSERAE_BIND_HOST=0.0.0.0The address the server binds. Feeds the --host default (image 0.381.0+); an explicit --host flag wins. Set :: for IPv6. Also used internally so loopback renders target [::1] instead of 127.0.0.1 under an IPv6 bind.

  The address the server binds. Feeds the --host default (image 0.381.0+); an explicit --host flag wins. Set :: for IPv6. Also used internally so loopback renders target [::1] instead of 127.0.0.1 under an IPv6 bind.

• TESSERAE_BIND_PORT=8765The port the server actually listens on. Feeds the --port default (image 0.378.0+), so a compose environment: entry is enough to move the web port; an explicit --port flag wins if both are given. Also used internally so loopback renders target the real bind port behind a reverse proxy or Docker port map.

  The port the server actually listens on. Feeds the --port default (image 0.378.0+), so a compose environment: entry is enough to move the web port; an explicit --port flag wins if both are given. Also used internally so loopback renders target the real bind port behind a reverse proxy or Docker port map.

• TESSERAE_CHROMIUM_PATH=bundledPath to a Chromium executable for the renderer, when the Playwright-bundled one can't be used.

  Path to a Chromium executable for the renderer, when the Playwright-bundled one can't be used.

• TESSERAE_DATA_ROOT=<repo>/dataData directory: settings, pages, schedules, event log, render cache, backups. The Docker image keeps the default and expects a volume at /app/data.

  Data directory: settings, pages, schedules, event log, render cache, backups. The Docker image keeps the default and expects a volume at /app/data.

• TESSERAE_EXPERIMENT_=unsetForce one of the optional features in Settings → System → Features on (1/true) or off (0/false) at deployment level. Names: COMPOSER (canvas editor), MCP (agent API), TEMPLATES (template marketplace). All are on by default, so this is mostly for switching one off, e.g. TESSERAE_EXPERIMENT_MCP=0. Overrides and locks the Settings toggle.

  Force one of the optional features in Settings → System → Features on (1/true) or off (0/false) at deployment level. Names: COMPOSER (canvas editor), MCP (agent API), TEMPLATES (template marketplace). All are on by default, so this is mostly for switching one off, e.g. TESSERAE_EXPERIMENT_MCP=0. Overrides and locks the Settings toggle.

• TESSERAE_FIRMWARE_API=https://api.tesserae.inkBase URL the firmware-update check queries. Development override.

  Base URL the firmware-update check queries. Development override.

• TESSERAE_FORWARDED_HOPS=1Trusted X-Forwarded-* proxy hops (Flask ProxyFix). Set 2 behind a double proxy, 0 to trust none.

  Trusted X-Forwarded-* proxy hops (Flask ProxyFix). Set 2 behind a double proxy, 0 to trust none.

• TESSERAE_HA_INGRESS
• TESSERAE_HOST_IP=auto-detectedThe LAN IP baked into frame URLs and the broker URL shown to panels. Required under Docker bridge networking, where auto-detection finds the container's unreachable 172.x address. May be an IPv6 address (0.381.0+); URLs bracket it automatically.

  The LAN IP baked into frame URLs and the broker URL shown to panels. Required under Docker bridge networking, where auto-detection finds the container's unreachable 172.x address. May be an IPv6 address (0.381.0+); URLs bracket it automatically.

• TESSERAE_HTTP_PORT=8765The advertised port, what panels and generated URLs should use when it differs from the bind port (reverse proxy, ports: ["8766:8765"] remap). Only the fallback before the first request captures the real external port.

  The advertised port, what panels and generated URLs should use when it differs from the bind port (reverse proxy, ports: ["8766:8765"] remap). Only the fallback before the first request captures the real external port.

• TESSERAE_IN_DOCKER=unsetSet to 1 by the Docker image. Hides the in-app self-update card and shows a docker compose pull hint instead.

  Set to 1 by the Docker image. Hides the in-app self-update card and shows a docker compose pull hint instead.

• TESSERAE_LOG_LEVEL=infoRoot log level. --log-level wins; the HA App's own Log level option wins there.

  Root log level. --log-level wins; the HA App's own Log level option wins there.

• TESSERAE_PARENT_PID
• TESSERAE_SECRET_KEY=derived64 hex chars (32 bytes) used to encrypt stored secrets (API keys, broker passwords) at rest. Unset, the key is derived from the persisted session secret. That survives restarts, but if the session secret is ever regenerated (a data folder restored without settings.json, a container recreated without its data volume) every stored secret reads back empty while the rest of the settings stay intact. P

  64 hex chars (32 bytes) used to encrypt stored secrets (API keys, broker passwords) at rest. Unset, the key is derived from the persisted session secret. That survives restarts, but if the session secret is ever regenerated (a data folder restored without settings.json, a container recreated without its data volume) every stored secret reads back empty while the rest of the settings stay intact. P

• TESSERAE_THREADS=24Waitress worker threads (minimum 4). Raise if many open editors + SSE streams starve renders.

  Waitress worker threads (minimum 4). Raise if many open editors + SSE streams starve renders.

• TESSERAE_TRUSTED_NETWORKS=unsetComma-separated CIDRs the auth gate treats as local on top of the fixed private ranges, e.g. 2001:db8:abcd::/48 for a LAN on an ISP-delegated IPv6 prefix. Clients in these networks fetch /renders/ without a session and, with the password disabled, reach the admin UI. Merged with the list under Settings → System → Authentication → Trusted networks.

  Comma-separated CIDRs the auth gate treats as local on top of the fixed private ranges, e.g. 2001:db8:abcd::/48 for a LAN on an ISP-delegated IPv6 prefix. Clients in these networks fetch /renders/ without a session and, with the password disabled, reach the admin UI. Merged with the list under Settings → System → Authentication → Trusted networks.
